- BT RFID & IC Reader HCR5-RF
- 【Brief】：
HCR5-RF Series
● Contact cards: ISO7816 compliance
● Contactless cards: ISO14443 Type A compliance
● Bluetooth & Micro-USB interface
● Micro-USB socket for rechargeable Li-Ion battery
● Low battery and charger indicator
● Multi LED indicator
- 【Series】：Portable Reader
- Description
-
Product Description
Item
Description
Contact Smart cards
Contact Mini-SIM cardsISO7816 T=0 and T=1, support Class A/B/C
Compliant EMV L1, PBOC L1Contactless cards
ISO14443 Type A, MIFARE Cards
Operating frequency: 13.56MHz
Operating Distance: 0 ~ 30mmLife time of Smart Card adaptor
Approx. 100,000 times of insertion
Life time of SIM Card adaptor
Approx. 5,000 times of insertion
Input voltage
5V DC, 500mA
Power consumption
Standby current 30mA
Operating current 70mA max.Rechargeable Li-Ion Battery
3.7V / 160mAh, 1 hours per charge;
Support 150 minutes continuous usedInterface
Bluetooth 4.0 LE
Micro-USB 2.0 HID Mode
Operating System & SDK support
iOS & Android (BLE)
Operating Temperature
0 ~ 40°c (32 ~ 104 °F)
Dimension (mm)
95 x 60 x 9.5 mm
Net Weight
40g
